Solis S5 50kW Quad 5x MPPT 3-Phase Grid Tie Inverter
R48,503.00
Solis S5 50kW Quad 5x MPPT 3-Phase Grid Tie Inverter – buy online from B&B Solar Power Solutions SA with fast, nationwide delivery across South Africa. Great prices, genuine warrantied stock, expert advice.
Free shipping on orders over R10,000.00
- Satisfaction Guaranteed
- No Hassle Refunds
- Secure Payments
Description
Overview
The inverter is the brain of any solar or backup system, seamlessly managing solar, battery and grid power and switching to backup in milliseconds when the grid goes down.
The Solis S5 50kW Quad 5x MPPT 3-Phase Grid Tie Inverter by Solis is available now from B&B Solar Power Solutions SA, with fast delivery to homes and businesses across South Africa. Order online or request a quote – our team is happy to help you choose the right product for your needs.
Why buy from B&B Solar Power Solutions SA?
- Seamlessly manages solar, battery and grid power
- Fast automatic switchover the moment the grid drops
- Works with leading lithium batteries
- Remote/app monitoring where supported
Specifications
| IP66, C5 Anti | Corrosion Level |
|---|---|
| Intelligent redundant fan | cooling |
| Intelligent string monitoring. Smart I | V curve scan |
| SA | NRS 097 certified and COCT Certified |
| Model | S5-GC50K |
| Energy Source | PV. |
| Max. input voltage | 1100 V |
| Rated voltage | 600 V |
| Start | up voltage: 195 V |
| MPPT voltage range | 180-1000 V |
| Max. input current | 5*32 A |
| Max. short circuit current | 5*50 A |
| MPPT number/Max. input strings number | 5/10 |
| Rated output power | 50 kW |
| Max. apparent output power | 55 kVA |
| Max. output power | 55 kW |
| Rated grid voltage | 3/N/PE, 220 V / 380 V, 230 V / 400 V |
| Rated grid frequency | 50 Hz / 60 Hz |
| Rated grid current | 76.0 A / 72.2 A |
| Max. output current | 83.6 A |
| Power Factor | >0.99 (0.8 leading – 0.8 lagging) |
| THDi | <3% |
| Max. efficiency | 98.7% |
| CEC efficiency | 98.3%. |
| DC reverse | polarity protection: Yes. |
| Short circuit protection | Yes. |
| Output over current protection | Yes. |
| Surge protection | DC Type II / AC Type II |
| Grid monitoring | Yes |
| Anti | islanding protection: Yes |
| Temperature protection | Yes |
| Strings monitoring | Yes |
| I/V Curve scanning | Yes |
| Integrated AFCI (DC arc | fault circuit protection): Optional |
| Integrated PID recovery | Optional |
| Integrated AC switch | Optional |
| Integrated DC switch | Yes |
| Dimensions(mm) | (W*H*D) 691*578*338 mm |
| Weight(kg) | 54.5 kg |
| Topology | Transformerless. |
| Self | consumption (night): <1W. |
| Operating ambient temperature range | -25~+60°C. |
| Ingress protection | IP66 |
| Cooling concept | Intelligent redundant fan cooling. |
| Max. operation altitude | 4000m. |
