Solis 20.0kW Dual MPPT 3-Phase Grid Tied Solar Kit

Description

Overview

Get the most out of every ray of sun. This charge controller maximises solar harvest and protects your battery bank for safe, efficient off-grid and backup charging.

The Solis 20.0kW Dual MPPT 3-Phase Grid Tied Solar Kit by Solis is available now from B&B Solar Power Solutions SA, with fast delivery to homes and businesses across South Africa. Order online or request a quote – our team is happy to help you choose the right product for your needs.

Why buy from B&B Solar Power Solutions SA?

• Maximises solar harvest and charging efficiency
• Protects and extends the life of your battery bank
• Ideal for off-grid and backup systems
• Proven, reliable technology

Specifications

1 x Solis 4G 20.0kW Dual MPPT 3	Phase Grid Tie Inverter.
3 x K&N 21A/800V	20A/1000V Single String DC Switch Disconnector.
2 x Multi Contact Cable Coupler Pack	MC4.
Installed capacity of PV system	kWP (stc): 20.250 KWp.
Orientation of the PV system	degrees from South: 0°.
Inclination of system	degrees from horizontal: 35°.
kWh/kWp (KK) from table	1,667 kWh/kWp.
Shade factor (SF)	1.00.
Estimated annual output (kWp x KK xSF)	33,764 kWh.
Number required	54.
Rating	375 Wp.
Length	1,765 mm.
Width	1,048 mm.
Voc at STC	41 V.
Vmpp at STC	34.3 V.
Impp at STC	10.94 A.
Isc at STC	11.61 A.
Array Power	20,250 Wp.
Phases	3.
No. of MPPT	2.
Rated AC Power	20,000 W.
Current	44.00 A.
Voltage	1000 V.
Min	180 V.
Max	850 V.
Quantity	1.
String Quantity	3.
Strings	1 * (2×18 / 1×18).
String Voc at 0 °	C787.82 / 787.82 V.
String Vmpp at 70 °	C520.16 / 520.16 V.
String Vmpp at 0 °	C671.42 / 671.42 V.
Input Isc at 70 °C	11.87 A.
Distance to Array	20 m.
Cable Area	6 mm2.
Voltage Drop	1.48 %.

Buy with confidence from B&B Solar Power Solutions SA

B&B Solar Power Solutions SA is your trusted supplier of solar power, water heating and energy-efficiency products, with fast, reliable delivery to homes and businesses across all nine provinces – from Mbombela to Cape Town and everywhere in between. We stock only genuine, warrantied products at competitive prices, and our team is happy to help you size the right system for your needs.

🚚 Enjoy FREE delivery on orders over R10,000 – use code BBSPS26 at checkout. Ready to order or need a quote? Contact us today.

What’s Included in This Kit

• 54 × Canadian Solar HiKu 375W Super High Power Mono PERC Solar Panel
• 1 × Solis 4G 20.0kW Dual MPPT 3-Phase Grid Tie Inverter — R48,077
• 1 × K&N 63A Three Phase AC Switch Disconnector
• 3 × K&N 21A/800V – 20A/1000V Single String DC Switch Disconnector
• 1 × 1000V SolarEdge Protection Box Type 2 For SE 25/27.7K Inverter
• 4 × MC4 Pre terminated cable 2m (Pack of 2) — R115
• 2 × Multi Contact Cable Coupler Pack – MC4 — R157
• 1 × Optional Roof Mounting System
• 2 × 18 / 1×18)
