CNBM 10m-330 330W Mono Solar Panel
R1,552.00
CNBM 10m-330 330W Mono Solar Panel – buy online from B&B Solar Power Solutions SA with fast, nationwide delivery across South Africa. Great prices, genuine warrantied stock, expert advice.
Free shipping on orders over R10,000.00
- Satisfaction Guaranteed
- No Hassle Refunds
- Secure Payments
Description
Overview
This high-efficiency solar panel turns South Africa’s abundant sunshine into clean, free electricity for your home or business – cutting your Eskom bill and keeping the power on through load-shedding.
The CNBM 10m-330 330W Mono Solar Panel by CNBM Solar is available now from B&B Solar Power Solutions SA, with fast delivery to homes and businesses across South Africa. Order online or request a quote – our team is happy to help you choose the right product for your needs.
Why buy from B&B Solar Power Solutions SA?
- High-efficiency cells that deliver strong yield in South Africa’s high-sun climate
- Tough, weather- and hail-resistant build for local conditions
- Cut your Eskom bill and reduce the impact of load-shedding
- Backed by a manufacturer warranty
Specifications
| Outstanding performance in low | light irradiance environments. |
|---|---|
| Excellent mechanical load resistance | Certified to withstand high wind loads(2400pa) and snow loads(5400pa). |
| Positive power tolerance | 0-+5w. |
| 10 | years 90% of Min. rated output power, and 25-years 80% of Min. rated output power warranty. |
| Type of Cells(mm) | Mono 99.5 x 182 |
| NO. of Cells and Connections | 4 ×19 =76 |
| Dimensions(mm)(L*W*H) | 1956mm × 765mm × 30 |
| Weight(kg) | 17 |
| Glass | 3.2mm Tempered Glass. |
| Encapsulation | EVA. |
| Backsheet | Multilayer Composite. |
| Junction | Box: IP67/IP68 |
| Cable | 4mm², 900mm. |
| Connector | MC4 and MC4 Compatible |
| Maximum System Voltage | 1000V |
| Operating Temperature | -45~+80°C |
| Maximum Series Fuse | 20A |
| Maximum Static Load, Back Side (e.x. Wind) | 2400PA |
| Application Grade | Class A |
| Rated Maximum Power | 330W. |
| Power Tolerance | 0 – +5W |
| Module Efficiency | 24.6% |
| Open Circuit Voltage | 53.57V. |
| Max Power Voltage | 46.39V. |
| Short Circuit Current (Isc) | 7.38A. |
| Max Power Current(Imp) | 7.13A. |
| Temperature Coefficient of Isc | +0.6% |
| Temperature Coefficient of Voc | 0.33% |
| Temperature Coefficient of Pmp | -0.45% |
